Dumbwaiter Elevator
CNDE-300
FOB
Quantity
Main Information: Conai dumbwaiter elevator is fast ,convenient and economical lifting transportation
elevator dumbwaiter,food elevator dumbwaiter,elevator for disabled
Dumbwaiter Elevator Standard Configuration
| 1.Car Design | ||
1 | Front wall | Hairline stainless steel |
2 | Car wall panel | Hairline stainless steel |
3 | Car flooring | Checked steel plate |
4 | Car Ceiling | Hairline stainless steel |
5 | Car door | Hairline stainless steel |
6 | Light | LED |
2.Landing Design | ||
Shaft door finish: | ||
1 | A: At ground floor | Hairline stainless steel |
2 | B: At typical floor | Hairline stainless steel |
| Entrance jambs | ||
3 | A: At ground floor | Hairline stainless steel |
4 | B: At typical floor | Hairline stainless steel |
3.Hall push button | ||
| 1 | At ground floor | Hairline stainless steel |
| 2 | Other floors | Hairline stainless steel |
| NO. | Rated capacity(KGS) | Speed(m/s) | Size of car(mm) | Car opening type(mm) | Shaft Size(W*D)(mm) | Windowsill Height(mm) | Top Height(mm) |
| 1 | 100 | 0.4 | 700*700*800 | 700*800 | 1200*900 | ≥700 | ≥3000 |
| 2 | 200 | 0.4 | 800*800*800 | 800*800 | 1300*1000 | ≥700 | ≥3000 |
